代码实现——LLVM IR Printer

文件用于标准化 LLVM IR（Intermediate Representation）中的函数、模块、循环、SCC（Strongly Connected Components），并将处理后的 IR 以标准格式写入指定目录。
它可以用于 优化前后 IR 结构对比，以及 去除调试信息 以提升 IR 可读性和一致性。
目的是制作数据集。
涵盖的功能有：

1. 标准化 IR 结构：
   • 清除 BasicBlock 和 Instruction 的名称，确保一致性。
   • 处理 Function、Module、Loop、LazyCallGraph::SCC 等不同 IR 单元。
2. 文件存储：
   • IR 处理后，存储到指定目录，按照 模块名-哈希值-时间戳-后缀.ll 进行命名，方便后续分析。
   • 利用 llvm::sys::fs::create_directories 自动创建存储目录，避免手动管理。
3. 哈希计算：
   • 采用 6 位十六进制哈希 计算函数名，避免冗长的文件名，并确保唯一性。
4. 模块名优化：
   • 去掉 LLVM 模块的完整路径，仅保留文件名，避免文件路径污染模块命名。

     #include "llvm/Analysis/LazyCallGraph.h"
     #include "llvm/Analysis/LoopInfo.h"
     #include "llvm/CodeGen/MachineFunction.h"
     #include "llvm/IR/BasicBlock.h"
     #include "llvm/IR/Function.h"
     #include "llvm/IR/Instruction.h"
     #include "llvm/IR/Module.h"
     #include "llvm/Support/FileSystem.h"
     #include "llvm/Support/Path.h"  // 关键修改：引入 LLVM 的路径处理库
     #include "llvm/Support/raw_ostream.h"
     #include <chrono>
     #include <ctime>
     #include <functional>
     #include <iomanip>
     #include <sstream>

     using namespace llvm;

     static void standardizeFunction(Function &F) {
       for (BasicBlock &BB : F) {
         BB.setName("");
         for (Instruction &I : BB) {
           I.setName("");
         }
       }
     }

     static void standardizeModule(Module &M) {
       for (Function &F : M)
         standardizeFunction(F);
     }

     static void standardizeLoop(Loop &L) {
       for (auto *BB : L.blocks()) {
         BB->setName("");
         for (Instruction &I : *BB)
           I.setName("");
       }
     }

     static void standardizeSCC(LazyCallGraph::SCC &S) {
       for (auto &N : S)
         standardizeFunction(N.getFunction());
     }

     static std::string get6HexHash(const std::string &Name) {
       std::hash<std::string> H;
       std::size_t V = H(Name);
       std::stringstream S;
       S << std::hex << std::setw(6) << std::setfill('0') << (V & 0xFFFFFF);
       return S.str();
     }

     template <typename IRUnitT>
     void standardizeAndWriteIR(IRUnitT &IR, const std::string &Suffix, const std::string &ShortTimestamp,
                                const std::string &OutputBaseDir = "/home/yz/clean/DBGMASTER/IR_DUMP_DIR/") {
       std::string ModuleName = "UnknownModule";
       std::string FuncHash = "000000";

       // 获取模块名称
       if constexpr (std::is_same_v<IRUnitT, Module>) {
         ModuleName = IR.getName().str();
         if (ModuleName.empty())
           ModuleName = "UnknownModule";
         else
           ModuleName = sys::path::filename(ModuleName).str(); // 仅获取文件名
         standardizeModule(IR);
       } else if constexpr (std::is_same_v<IRUnitT, Function>) {
         Module *M = IR.getParent();
         if (M && !M->getName().empty())
           ModuleName = sys::path::filename(M->getName()).str();
         std::string FuncName = IR.getName().str();
         if (FuncName.empty())
           FuncName = "UnknownFunc";
         FuncHash = get6HexHash(FuncName);
         standardizeFunction(IR);
       } else if constexpr (std::is_same_v<IRUnitT, Loop>) {
         Function *F = IR.getHeader() ? IR.getHeader()->getParent() : nullptr;
         if (F) {
           Module *M = F->getParent();
           if (M && !M->getName().empty())
             ModuleName = sys::path::filename(M->getName()).str();
           std::string FuncName = F->getName().str();
           if (!FuncName.empty())
             FuncHash = get6HexHash(FuncName);
         }
         standardizeLoop(IR);
       } else if constexpr (std::is_same_v<IRUnitT, LazyCallGraph::SCC>) {
         ModuleName = "SCC";
         standardizeSCC(IR);
       } else {
         errs() << "Unknown IR type in standardizeAndWriteIR, skipping...\n";
         return;
       }

       // 计算最终输出目录（IR_DUMP_DIR/module_name/）
       std::string ModuleOutputDir = OutputBaseDir + ModuleName + "/";
       if (std::error_code EC = sys::fs::create_directories(ModuleOutputDir)) {
         errs() << "Error: Failed to create directory: " << ModuleOutputDir << " (" << EC.message() << ")\n";
         return;
       }

       // 计算输出文件名
       std::string OutputFilename = ModuleOutputDir + ModuleName + "-" + FuncHash + "-" + ShortTimestamp + "-" + Suffix + ".ll";

       // 打开文件进行写入
       std::error_code EC;
       raw_fd_ostream OutFile(OutputFilename, EC, sys::fs::OF_None);
       if (!EC) {
         if constexpr (std::is_same_v<IRUnitT, Module> || std::is_same_v<IRUnitT, Function>) {
           IR.print(OutFile, nullptr);
         } else {
           errs() << "Unsupported IR type for printing.\n";
         }
       } else {
         errs() << "Failed to write IR to file: " << OutputFilename << " (" << EC.message() << ")\n";
       }
     }

可以直接用这个 patch 包（仅针对 SimplifyCFG 当前）：

diff --git a/llvm/include/llvm/Transforms/Utils/MyExtension/StandardIRPrinter.h b/llvm/include/llvm/Transforms/Utils/MyExtension/StandardIRPrinter.h
new file mode 100644
index 000000000000..29de766eac9f
--- /dev/null
+++ b/llvm/include/llvm/Transforms/Utils/MyExtension/StandardIRPrinter.h
@@ -0,0 +1,129 @@
+#include "llvm/Analysis/LazyCallGraph.h"
+#include "llvm/Analysis/LoopInfo.h"
+#include "llvm/CodeGen/MachineFunction.h"
+#include "llvm/IR/BasicBlock.h"
+#include "llvm/IR/Function.h"
+#include "llvm/IR/Instruction.h"
+#include "llvm/IR/Module.h"
+#include "llvm/Support/FileSystem.h"
+#include "llvm/Support/Path.h"  // 关键修改：引入 LLVM 的路径处理库
+#include "llvm/Support/raw_ostream.h"
+#include <chrono>
+#include <ctime>
+#include <functional>
+#include <iomanip>
+#include <sstream>
+
+using namespace llvm;
+
+#define PRIOR_PRINTER(Any, PASS_NAME, TIMESTAMP_VAR) \
+  auto Now = std::chrono::system_clock::now(); \
+  auto TIMESTAMP_VAR = std::chrono::duration_cast<std::chrono::nanoseconds>(Now.time_since_epoch()).count(); \
+  std::string TIMESTAMP_VAR##Str = std::to_string(TIMESTAMP_VAR); \
+  std::string TIMESTAMP_VAR##Short = TIMESTAMP_VAR##Str.substr(TIMESTAMP_VAR##Str.length() - 8); \
+  LLVM_DEBUG(dbgs() << "TIMENOW-" << TIMESTAMP_VAR##Short << "\n"); \
+  standardizeAndWriteIR(Any, PASS_NAME "-before", TIMESTAMP_VAR##Short);
+
+#define POST_PRINTER(Any, PASS_NAME, TIMESTAMP_VAR) \
+  standardizeAndWriteIR(Any, PASS_NAME "-after", TIMESTAMP_VAR##Short);
+
+static void standardizeFunction(Function &F) {
+  for (BasicBlock &BB : F) {
+    BB.setName("");
+    for (Instruction &I : BB) {
+      I.setName("");
+    }
+  }
+}
+
+static void standardizeModule(Module &M) {
+  for (Function &F : M)
+    standardizeFunction(F);
+}
+
+static void standardizeLoop(Loop &L) {
+  for (auto *BB : L.blocks()) {
+    BB->setName("");
+    for (Instruction &I : *BB)
+      I.setName("");
+  }
+}
+
+static void standardizeSCC(LazyCallGraph::SCC &S) {
+  for (auto &N : S)
+    standardizeFunction(N.getFunction());
+}
+
+static std::string get6HexHash(const std::string &Name) {
+  std::hash<std::string> H;
+  std::size_t V = H(Name);
+  std::stringstream S;
+  S << std::hex << std::setw(6) << std::setfill('0') << (V & 0xFFFFFF);
+  return S.str();
+}
+
+template <typename IRUnitT>
+void standardizeAndWriteIR(IRUnitT &IR, const std::string &Suffix, const std::string &ShortTimestamp,
+                           const std::string &OutputBaseDir = "/home/yz/clean/DBGMASTER/IR_DUMP_DIR/") {
+  std::string ModuleName = "UnknownModule";
+  std::string FuncHash = "000000";
+
+  // 获取模块名称
+  if constexpr (std::is_same_v<IRUnitT, Module>) {
+    ModuleName = IR.getName().str();
+    if (ModuleName.empty())
+      ModuleName = "UnknownModule";
+    else
+      ModuleName = sys::path::filename(ModuleName).str(); // 仅获取文件名
+    standardizeModule(IR);
+  } else if constexpr (std::is_same_v<IRUnitT, Function>) {
+    Module *M = IR.getParent();
+    if (M && !M->getName().empty())
+      ModuleName = sys::path::filename(M->getName()).str();
+    std::string FuncName = IR.getName().str();
+    if (FuncName.empty())
+      FuncName = "UnknownFunc";
+    FuncHash = get6HexHash(FuncName);
+    standardizeFunction(IR);
+  } else if constexpr (std::is_same_v<IRUnitT, Loop>) {
+    Function *F = IR.getHeader() ? IR.getHeader()->getParent() : nullptr;
+    if (F) {
+      Module *M = F->getParent();
+      if (M && !M->getName().empty())
+        ModuleName = sys::path::filename(M->getName()).str();
+      std::string FuncName = F->getName().str();
+      if (!FuncName.empty())
+        FuncHash = get6HexHash(FuncName);
+    }
+    standardizeLoop(IR);
+  } else if constexpr (std::is_same_v<IRUnitT, LazyCallGraph::SCC>) {
+    ModuleName = "SCC";
+    standardizeSCC(IR);
+  } else {
+    errs() << "Unknown IR type in standardizeAndWriteIR, skipping...\n";
+    return;
+  }
+
+  // 计算最终输出目录（IR_DUMP_DIR/module_name/）
+  std::string ModuleOutputDir = OutputBaseDir + ModuleName + "/";
+  if (std::error_code EC = sys::fs::create_directories(ModuleOutputDir)) {
+    errs() << "Error: Failed to create directory: " << ModuleOutputDir << " (" << EC.message() << ")\n";
+    return;
+  }
+
+  // 计算输出文件名
+  std::string OutputFilename = ModuleOutputDir + ModuleName + "-" + FuncHash + "-" + ShortTimestamp + "-" + Suffix + ".ll";
+
+  // 打开文件进行写入
+  std::error_code EC;
+  raw_fd_ostream OutFile(OutputFilename, EC, sys::fs::OF_None);
+  if (!EC) {
+    if constexpr (std::is_same_v<IRUnitT, Module> || std::is_same_v<IRUnitT, Function>) {
+      IR.print(OutFile, nullptr);
+    } else {
+      errs() << "Unsupported IR type for printing.\n";
+    }
+  } else {
+    errs() << "Failed to write IR to file: " << OutputFilename << " (" << EC.message() << ")\n";
+  }
+}
diff --git a/llvm/lib/Transforms/Scalar/SimplifyCFGPass.cpp b/llvm/lib/Transforms/Scalar/SimplifyCFGPass.cpp
index 4e437e9abeb4..348c30934357 100644
--- a/llvm/lib/Transforms/Scalar/SimplifyCFGPass.cpp
+++ b/llvm/lib/Transforms/Scalar/SimplifyCFGPass.cpp
@@ -42,6 +42,7 @@
 #include "llvm/Transforms/Scalar/SimplifyCFG.h"
 #include "llvm/Transforms/Utils/Local.h"
 #include "llvm/Transforms/Utils/SimplifyCFGOptions.h"
+#include "llvm/Transforms/Utils/MyExtension/StandardIRPrinter.h"
 #include <utility>
 using namespace llvm;

@@ -373,6 +374,7 @@ void SimplifyCFGPass::printPipeline(

 PreservedAnalyses SimplifyCFGPass::run(Function &F,
                                        FunctionAnalysisManager &AM) {
+  PRIOR_PRINTER(F, "simplifycfg", Timestamp);
   auto &TTI = AM.getResult<TargetIRAnalysis>(F);
   Options.AC = &AM.getResult<AssumptionAnalysis>(F);
   DominatorTree *DT = nullptr;
@@ -383,6 +385,7 @@ PreservedAnalyses SimplifyCFGPass::run(Function &F,
   PreservedAnalyses PA;
   if (RequireAndPreserveDomTree)
     PA.preserve<DominatorTreeAnalysis>();
+  POST_PRINTER(F, "simplifycfg", Timestamp);
   return PA;
 }
